Jen, a UX researcher at BECU, walks through a real case study in which she used a multi-method research approach, including heuristic evaluation, customer interviews, and contextual inquiry, to build a service design blueprint for an enterprise security reporting process. The blueprint mapped a deeply manual, multi-system workflow and surfaced both improvement opportunities and the limits of automation. The talk also demonstrates how the service design blueprint framework can be adapted beyond its standard template to fit the specific questions a team needs to answer.
Key Takeaways
- Modify the service design blueprint framework to fit your team's actual questions. The swim lanes do not need to match any standard template. Drop rows that do not add value and add rows that surface what matters.
- Start physical or at low resolution. Paper stickies and a whiteboard make it easy to catch errors early and invite conversation. Move to a digital format, such as a digital whiteboard or spreadsheet, only once the flow is confirmed.
- Contextual inquiry reveals what interviews cannot. Observing a practitioner build a report in real time surfaces steps, errors, and workarounds the person themselves is not aware of and would never report in a post-event interview.
- A service design blueprint is a tool for organizational alignment, not just documentation. Making the process visible, especially at large physical scale, brought developers and managers into the conversation and broke down silos that had persisted for years.
- Full automation is rarely a simple fix. The blueprint showed managers that the reporting process involved too many systems and manual decision points to automate with a switch flip, recalibrating expectations before resources were committed.
- Meet stakeholders where they are with deliverables. Translating the blueprint into a spreadsheet rather than a design tool made the artifact accessible to the entire team and reduced questions directed at the researcher.
Questions & Answers
- Do you always recommend starting with a physical representation first, or can you get the same benefits starting in a spreadsheet?
- Given the choice today, the speaker would use a digital whiteboard rather than paper stickies or a spreadsheet. A digital whiteboard is as flexible as physical stickies for moving things around, allows screenshots to be embedded cleanly alongside the steps, and produces an artifact that can be cleaned up into a polished deliverable. Most teams now have access to some form of digital whiteboard tool.
- Did you have any issues building trust with Bro Sales so that he would share his real process with you?
- Trust built quickly because the researcher adopted an explicit apprentice posture. She told Bro Sales to treat her as someone who knew nothing and to walk her through everything. Asking questions without defensiveness, sitting alongside him for extended periods, and being clear that she was there to learn rather than evaluate his work made the dynamic comfortable. The researcher noted that most people respond well to being positioned as the expert in the room.
- What format were the customer interviews conducted in, and what would you recommend?
- The interviews in this project were conducted by phone. In retrospect, the speaker would recommend video calls such as Zoom, because they allow both parties to pull up the report document on screen at the same time and because seeing a participant's facial reactions provides richer data than voice alone.
- What was your favorite part of the research process?
- Contextual inquiry. Sitting with Bro Sales and watching him work in real time surfaced errors and intermediate steps he was not even aware he was taking. For example, he described his next step as going to one system but then navigated to a different one first. That kind of observation is impossible to capture in a post-event interview.
Session Notes
What Is Enterprise Software
Enterprise software serves the needs of an organization rather than an individual user. Its defining characteristics create specific UX challenges.
- Users are often in the system for long stretches, sometimes all day.
- Functionality is frequently tied to legacy systems, making the experience feel dated.
- The person who purchases the software is rarely the person who uses it daily. Procurement or technology leadership typically makes the buying decision.
- Enterprise software rarely receives focused UX investment because organizations simply need the solution to exist.
Common examples include Jira, Salesforce, Zoho, and WordPress, covering functions such as HR, payroll, CRM, and marketing.
What Is Service Design, and Why Does It Apply Here
Service design is the practice of organizing people, resources, and processes to improve the employee experience and, indirectly, the customer experience. This maps closely onto the logic of enterprise software: in both cases, improving the experience of the person doing the work has downstream effects on the customer they serve.
The Service Design Blueprint
A service design blueprint uses horizontal swim lanes to represent different layers of an experience, such as customer actions, staff actions, and supporting systems, and vertical columns to represent steps in a process. The framework from Adaptive Path was used as a starting point, but the speaker adapted it significantly for this project.
The Case Study: Security Reporting at a Managed Security Company
The Business Problem
The company monitored internet traffic for corporate clients and delivered monthly or quarterly reports summarizing network activity and security threats. The business ask was to automate the creation of those reports. Before designing a solution, the researcher needed to understand what was wrong with the current report and how it was actually built.
Problems with the Existing Reports
- Building a single report took nearly two hours of manual work and did not scale.
- Data came from multiple separate sources.
- Clients were not consulted when the reports were designed.
- Visual presentation was inconsistent across the document.
- Charts used 3D bar graphs with wide number scales, making comparisons difficult.
- A table of IP addresses provided no context or interpretation.
- One chart tracked the count of tickets sent per month, which clients said they did not care about.
- A chart showing ticket resolution time used seconds on the x-axis (with a maximum of 28,619 seconds) and included half-number increments on the y-axis, even though a fractional ticket cannot exist.
The Multi-Method Research Plan
The researcher designed a four-part plan to investigate the problem before making any recommendations.
- Heuristic evaluation of the existing reports to identify design and usability problems.
- One-on-one customer interviews to learn what clients actually needed from the reports.
- Contextual inquiry with the person who built the reports to understand the production process step by step.
- Service design blueprint to synthesize all findings, map the end-to-end process, and surface gaps and opportunities.
Heuristic Evaluation
The evaluation was not tied to a formal heuristic set. The goal was a quick examination of the status quo, looking for inconsistencies and anything that would confuse a non-expert reader. The reports were built by technically skilled security analysts who were not trained in communication design. The evaluation confirmed the charts described above were problematic and set the agenda for later interview questions.
Customer Interviews
Clients who received the reports were interviewed one on one. Their core feedback was consistent.
- Reports needed to provide actionable items they could bring to their leadership.
- Clients wanted interpretation, not just status. They wanted to know what to do about a problem, not only that a problem existed.
- Reports should reflect current industry trends and threats happening in the world.
- Content should be personalized to their company and industry. Generic articles included in the reports were not useful.
- Simply put: the reports did not contain the information clients needed.
"If we are in trouble, I don't want to know that there is a problem. I want to know what to do about it."
Contextual Inquiry
The researcher sat with the primary report builder, referred to throughout as "Bro Sales," and observed him building a report from start to finish while asking questions along the way. Key findings from the observation included the following.
- The process required a large number of separate systems, websites, scripts, and manual calculations.
- Bro Sales was not fully aware of how many systems he was using until the process was mapped out.
- The method surfaced errors in real time, including instances where numbers entered into scripts did not match what he had described as his intended next step.
- Observation revealed workarounds and intermediate steps that would never have been reported in a post-event interview.
After the observation sessions, the researcher sketched a rough map of the steps and associated systems on a small physical whiteboard. Keeping this artifact low-resolution made it easy to revise before investing time in a polished format.
Building the Service Design Blueprint
Physical Format First
Without access to a digital whiteboard, the researcher built the blueprint at large physical scale using flip-chart paper and sticky notes. The final version wrapped around five cubicles in the office. The swim lanes were customized for this project.
- Yellow stickies: the discrete actions or steps in building the report.
- Orange stickies: additional observations noted during contextual inquiry that were not formal steps.
- Pink stickies: the researcher's editorial comments, gap flags, and "how might we" ideas, kept visually separate from observed behaviors.
- Screenshots: printed and attached to show exactly what was on screen at each step.
- Colored dots: indicated which software or system was involved at each step.
Benefits of Going Large and Physical
- Created visibility into a process that had previously been invisible to the broader organization.
- Allowed Bro Sales to review and confirm the flow, which surfaced sequencing errors that were easy to correct with stickies.
- Attracted developers and managers who were not part of the original project, drawing them into the conversation.
- Surfaced the complexity of automation to managers who had assumed it would be straightforward.
- For the first time, managers could see how many steps and systems were involved in producing a single report.
Translating to a Spreadsheet
Once the physical blueprint was confirmed as accurate, the researcher transferred it into a spreadsheet, using cell colors that matched the sticky note colors from the physical version. The choice of a spreadsheet over design software was intentional: it matched the tools stakeholders were already comfortable with, kept the file size small, and made the document accessible to anyone on the team without requiring the researcher to field questions in person.
"Form follows function, my dear friends."
Outcome
The blueprint and accompanying research led to a clear decision: full automation of the report was not feasible given the number of systems, manual steps, and judgment calls involved. However, there were targeted opportunities to streamline parts of the process. Recommendations also covered visual consistency improvements to the report itself and new content approaches based on what clients said they needed.
Adapting the Blueprint Framework: A Theme Park Example
To illustrate the flexibility of the service design blueprint, the speaker walked through a hypothetical theme park design scenario. Using a persona of a group that includes an elderly person with mobility issues, the team could map each attraction with custom swim lanes.
- Customer touch points at each attraction.
- Services provided at that attraction.
- Direct employee interactions relevant to the persona.
- Positive aspects of the attraction for this persona.
- Negative or problematic aspects for this persona.
- "How might we" brainstorming row for improvement opportunities.
This example shows that the standard swim lane labels from the framework can be replaced entirely. The blueprint's value comes from the structure of mapping steps against dimensions of experience, not from using any fixed set of rows.
Broader Lessons and Recommendations
- Service design blueprints can be built solo or with a cross-functional team. Bringing in developers, product colleagues, or even clients adds perspectives and builds shared ownership of the findings.
- No special tools are required. Paper, stickies, and screenshots are sufficient. A digital whiteboard is a good modern equivalent.
- You do not need to understand all the underlying systems to build a blueprint. Enough context to name the system and understand why it is used is sufficient.
- Talk to both internal experts and external users. Internal subject matter experts may understand why certain information is included; external users can tell you whether it is landing and what they actually need.
- Surface low-hanging fruit. Even when full automation is off the table, reducing time on task, simplifying steps, and improving data presentation are concrete wins worth recommending.
